| Brand: |
Viessmann |
| Part Number: |
2670 |
| Our Code: |
VN2670 |
This newly developed ballast renewal machine from Plasser & Theurer is equipped with two drive options – electric and diesel-electric (hybrid) – by
means of a 600 kW diesel engine. Driving engines and hydraulics are always driven electrically. The electric drive allows for a low-maintenance, as well
as silent and low-emission operation (CO2-reduced).
The trendsetting design is mainly function-orientated and keyed to enhance work safety. The model is to a high degree a copy of the prototype in terms
of both function and design.
Innovation by Viessmann:
Operation optional in drive mode or working mode travelling forward at ca. 3 km/h with tamping unit moving vertically and horizontally. Pantograph motor-
driven, several light functions. Digital decoder with original sound for electric resp. diesel engine for DCC, MM and analogue mode AC/DC, compatible
with RailCom. Excellently synchronized tamping unit with the drive motors and the sound. Premium two-part model with zinc diecasting chassis and two
synchronized drive motors ensuring a dynamic yet sensitive train operation, supported by integral current memories.
With coupler pockets acc. NEM 362 and attached system coupling.
Dimensions: Lob 39,3 x W 3,9 x H (without/with pantograph) 5,1/7,6 cm.
Functions in analogue mode:
- Driving mode forward / reverse
- Switchable functions: Working mode with fully functional tamping unit, synchronized with the drive motors and the sound, incl. warning light and working lights
- Sound active
- Light active (configurable by CVs)
Functions in digital mode:
- Driving mode forward/reverse
- Switchable functions: Working mode with fully functional tamping unit, synchronized with the drive motors and the sound (slide movement forward and backward, tamping movement, also all individually switchable)
- Sound, horn
- Pantograph up/down
- Shunting mode
Switchable light functions in digital mode:
- Coach lighting white or blue
- Headlights switchable individually acc. to direction of travel as well white/red, high and low beam switchable
- Stoplight
- High beam
- Operator’s cab lighting
- Work space lighting
- Warning light front and back |
|
|
